4EES-4/4EES-4Y 4EC-4.2Y low noise Semi-hermetic Condensing Unit for
freezing room compressor unit
Quick Detail
Semi-hermetic Reciprocating compressor ECOLINE Series Condensing Unit
The advantage of the compressor:
Energy efficient
High-efficiency profile
Infinite or closely stepped capacity control
Optimum economiser operation
Universal
R134a, R407C and R22 (R404A, R507A upon request)
With and without economiser (ECO)
Flexible
Dual capacity control
Changeable between 4-stage and infinite capacity control-without
retrofitting the compressor
Suction and discharge gas connections can be rotated in 90"
increments
Descrition
Specification
| HP | Compressor | Condenser
Surface
M2 | Voltage | Cooling capacity(W) | Axial Fans |
| (V-Ph-Hz) | Evaporating temperature(°C) |
| -35 | -30 | -25 | -20 | -15 | N°x Diameter |
| 2 | 2FES-2Y | 16 | 380-3-50 | 1000 | 1420 | 1910 | 2480 | 3140 | 1 x 350 |
| 2 | 2EES-2Y | 16 | 380-3-50 | 1280 | 1820 | 2450 | 3190 | 4050 | 1 x 400 |
| 2 | 2DES-2Y | 16 | 380-3-50 | 1600 | 2240 | 2990 | 3870 | 4890 | 1 x 400 |
| 3 | 2CES-3Y | 24 | 380-3-50 | 2110 | 2890 | 3810 | 4880 | 6120 | 2 x 350 |
| 3 | 4FES-3Y | 24 | 380-3-50 | 2380 | 3170 | 4120 | 5250 | 6580 | 2 x 350 |
| 4 | 4EES-4Y | 32 | 380-3-50 | 3010 | 4020 | 5240 | 6690 | 8390 | 2 x 400 |
| 5 | 4DES-5Y | 42 | 380-3-50 | 3600 | 4800 | 6260 | 8000 | 10040 | 2 x 400 |
| 6 | 4CES-6Y | 48 | 380-3-50 | 4220 | 5690 | 7480 | 9610 | 12120 | 2 x 400 |
| 8 | 4TES-9Y | 64 | 380-3-50 | 4840 | 6740 | 9030 | 11780 | 15040 | 2 x 450 |
| 10 | 4PES-12Y | 80 | 380-3-50 | 5040 | 7200 | 9830 | 13010 | 16790 | 2 x 450 |
| 12 | 4NES-14Y | 96 | 380-3-50 | 6580 | 9140 | 12240 | 15950 | 20350 | 4 x 400 |
| 15 | 4HE-18Y | 120 | 380-3-50 | 10070 | 13570 | 17720 | 22600 | 28350 | 4 x 400 |
| 20 | 4GE-23Y | 160 | 380-3-50 | 12320 | 16290 | 21000 | 26550 | 33050 | 4 x 400 |
| 25 | 6HE-28Y | 200 | 380-3-50 | 14800 | 19970 | 26100 | 33300 | 41750 | 4 x 400 |
| 30 | 6GE-34Y | 240 | 380-3-50 | 18920 | 24850 | 31800 | 39950 | 49400 | 2 x 600 |
| 40 | 6FE-44Y | 320 | 380-3-50 | 21900 | 29250 | 37750 | 47650 | 59100 | 2 x 600 |
Advantage
offers complete range of Refrigeration Systems with all types of
Compressors i.e. , and Copeland. The types of units specialized in
manufacturing are :
• Semi Hermetic Refrigeration System
• Sealed Refrigeration System
• 2-stage semi hermetic Refrigeration System
• Screw Compressor Refrigeration System
• Parallel Compressors rack Refrigeration Systems
• Evaporators
. Blast Freezers
Our Services
A. Individuation & CustomizationRefrigeration industry, cold storage engineering; Agriculture,
food, restaurant, chemical industry; we can undertake designs according to customer's
requirements.
B. Excellent warranty
KUB provides up to one year warranty period. If there is any
product quality problems, we will return processing, and is
responsible in the end.
We provide excellent service to solve your worries.
Shanghai KUB Refrigeration Equipment Co., Ltd is an advanced
enterprise specializing in design,
manufacture and trade of refrigeration equipment.
Founded in 2000 We have adopted internationally advanced technology
to meet all the different needs of our
diverse customers.
Main products include: box type & open type condensing units,air cooled,water cooled
condensing units,
mono block split type condensing units, low temperature screw condensing units,compressor racks, industrial chillers,D-series air coolers,double side blowing air coolers,water
defrosting air coolers, air cooled condenser,
tube-shell water cooled condensers, tube-shell evaporator and electrical control boxes,etc.
All of our units adopt world famous brand compressors such as
KUB,Carrier,Carlyle , Copeland,
Emerson,Maneurop,Tecumseh,danfoss etc.,with excellent performance a beautiful
appearance.
They are widely used in cold storage, hotels,industrial
processes,medical industries, chemical industries,refrigerated
trucks,vessel industries all other places where cold storage is needed.
Our products and solutions have been widely applied in the
fast-growing Chinese market,providing tens of
thousands of industrial equipment in machinery,electronics,plastics, textile,
food,medical,chemical industry andrenewable energy and related fields.
KUB is widely recognized and respected by manufacturers,technicians and end users in the industry.
We export our products all over the world to countries in locations
such as Europe,Middle East,Southeast
Asia, Africa,etc. and we support our customers with high quality products and turnkey
solutions.
Packaging & Shipping
Cold storage refrigeration condensing air-cooled unit :
The company has advanced information network technology and
excellent location, a sound management system and modern means of
communication and multi-faceted services. We insist on everything
from the actual needs of customers, the implementation of the
entire transport monitoring service is available 24 hours a day.
These are the goods on time, safe, efficient destination to provide
effective protection.
