NTZ068 Low Temperature Refrigeration Condensing Unit Blue Color

Ask Lasest Price
Brand Name :	KUB
Model Number :	NTZ068
Certification :	CE
Price :
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	1000 Piece/Pieces per Year
Delivery Time :	7

Add to Cart

Product Details
Company Profile

NTZ068 Low Temperature Refrigeration Condensing Unit Blue Color

Products Features

◆Widely Applied To Vegetable And Fruits Fresh Preservation,Logistic Center,Fish Processing Center,Ice Machine, Ice Cream
Machine, Medium-Low Temp Cold Storage, Application Temp Range
From +5°C To -35°C
◆Maneurop Series Refrigeration Unit Adopts Equiped With Maneurop Mt, Mtz, Ntz Series Hermetic Compressor And R22, R404a
◆High Quality Condenser, Branded Accessories, High Efficiency,Energy Saving, Low Noise, Stable Operation,

NTZ068 Low Temperature Refrigeration Condensing Unit Blue Color

Unit Model	Power	Cooling Capacity	Air Condenser			Evaporating Temperature(℃)							Connectlon Spec(mm)		Dimenslon (mm)
Unit Model	HP	w	Air Flow (mᵌ/h)	Fan Dia (mm)	Power 50/60(Hz)	-20	-15	-10	-5	0	5	10	Inlet	outlet	AxBxC
HH-MGM28	2.5	4700	3000	1×400	380V	一	一	-	一	6330	7720	9280	12	10	600×700×575
HH-MGM36	3	6010	2*1800	2×350	380V	3070	4110	5300	6630	8020	9710	11600	16	10	600×700×575
HH-MGM50	4.2	7400	2*3000	2×400	380V	3740	4950	6430	8240	10200	12800	15900	22	12	1010×710×575
HH-MGM64	53	9780	2*3000	2×400	380V	4710	6400	7520	10750	13300	16500	21100	22	12	1050×710×675
HH-MGM80	6.7	12380	2*4500	2×450	380V	6000	8150	10650	13530	16600	20400	24700	28	16	1050×710×775
HH-MGM100	8.3	14340	4*3000	4×400	380V	7180	9700	12700	16260	19900	24700	30400	28	16	1250×810×875
HH-MGM125	10	19190	4*3000	4×400	380V	9800	13000	16860	21380	26100	32200	39300	28	16	1250×810×980
HH-MGM160	13.3	24090	4*3000	4×400	380V	12460	16430	21190	26830	32800	40500	49500	28	16	1250×810×1200
HH-FH22-MT28H	2.5	4700	1*3000	1×400	380V	2190	3030	3660	4700	5890	7220	8720	12	10	700×600×580
HH-FH28-MT36H	3	6010	2*1800	2×350	380V	2890	3950	4710	6010	7470	9090	10900	16	10	1050×710×530
HH-FH42-MT50H	4	7400	2*3000	2×400	380V	3530	4740	5680	7400	9470	11940	14860	22	12	1050×710×580
HH-FH49-MT64H	5	9780	2*3000	2×400	380V	4100	5790	7570	9780	12370	15370	18830	22	12	1050×710×580
HH-FH60-MT80H	6.7	12380	2*4500	2×450	380V	5380	7530	9670	12380	15500	19060	23110	22	12	1250×710×580
HH-FH80-MT100H	8	14340	4*3000	4×400	380V	6250	8750	11010	14340	18270	22870	28190	28	16	1010×810×980
HH-FH100-MT125H	10	19190	4*3000	4×400	380V	8960	12100	14990	19190	24120	29880	36540	28	16	1010×810×1280
HH-FH130-MT160H	13	24090	4*3000	4×400	380V	11500	15400	18850	24090	30290	37560	46000	28	16	1010×810×1280
HH-FH18-MTZ28M	2.5	2730	1*3000	1×400	380V	一	2160	3110	4220	5520	7030	8770	12	10	700×600×580
HH-FH22-MTZ36M	3	3560	1*3000	1×400	380V	一	3270	4400	5710	7200	8920	10900	16	10	1050×710×530
HH-FH33-MTZ50M	4	4280	2*3000	2×400	380V	一	3880	5440	7330	9570	12200	15300	22	12	1050×710×580
HH-FH42-MTZ64M	5	5690	2*3000	2×400	380V	一	5020	7060	9490	12400	15700	19600	22	12	1050×710×580
HH-FH49-MTZ80M	6.7	7330	2*3000	2×400	380V	一	6850	9380	12400	15800	19900	24500	22	12	1050×710×680

model	TE	-45		-40		-35		-30		-25		-20		-15		-10
model	TC	P.F.	PA.	P.F.	P.A.	P.F.	P.A	P.F.	P.A.	P.F.	P.A	P.F.	P.A	P.F.	P.A	P.F.	P.A.
NTZ 048	30	644	0.5	774	0.7	1160	0.9	1636	1.1	2211	1.27	2896	1.42	3700	1.54	4635	1.62
	40	278	0.41	538	0.64	860	0.87	1255	1.1	1732	1.33	2303	1.54	2977	1.73	3766	1.88
	50	-		312	0.53	568	0.79	879	1.06	1257	1.33	171	1.59	2252	1.84	2893	2.07
	60	-		-	-	298	0.65	523	0.95	797	1.26	1132	1.57	1537	1.87	2025	2.17
NTZ 068	30	782	0.84	1212	1.12	1770	1.4	2471	1.66	3337	1.91	4385	2.13	5637	2.32	7112	2.48
	40	484	0.71	845	1.03	1309	1.35	1894	1.68	2620	2.01	3507	2.33	4576	2.63	5847	2.92
	50			492	0.88	853	1.24	1313	1.61	1890	2.01	2605	2.4	3480	2.81	4537	3.2
	60			-	-	437	1.05	761	1.46	1179	1.9	1711	2.37	2380	2.85	3210	3.34
NTZ096	30	1122	1.17	1647	1.48	2342	1.79	3237	2.09	4363	2.38	5750	2.66	7431	2.92	9438	3.15
	40			1152	1.37	1730	1.73	2483	2.12	3442	2.52	4639	2.93	6109	3.34	7884	3.75
	50			-			1.59	1697	2.03	2463	2.51	3442	3.02	4669	3.57	6183	4.13
	60							953	1.85	1500	2.38	2231	2.97	3185	3.62	4402	4.31
NTZ 108	30	1068	1.44	1771	1.76	2672	2.11	3796	2.47	5168	2.83	6815	3.17	8763	3.48	1038	3.74
	40	-		1292	1.75	2048	2.14	2986	2.57	4132	3.02	5512	3.48	7153	3.93	9083	4.36
	50					1389	2.08	2127	2.55	3031	3.07	4128	3.62	5447	4.18	7015	4.74
	60							1270	2.42	1917	2.98	2715	3.59	3692	4.24	4880	4.91
NTZ136	30	1796	1.89	2617	2.4	3661	2.89	4961	3.36	6552	3.79	8469	4.17	10749	4.51	13427	4.79
	40			191	2.33	2788	2.9	3882	3.46	5228	4.02	6864	4.56	8823	5.07	m1148	5.56
	50			-		1941	2.83	2816	3.47	3905	4.13	5244	4.8	6871	5.47	8829	6.14
	60						-	1793	3.5	2609	4.23	3635	5.01	4911	5.82	6483	6.65
NTZ 215	30	2714	2.74	4019	3.43	5641	4.1	7623	4.73	10008	5.31	12842	5.8	16169	6.19	20034	6.45
	40	1701	2.51	2854	3.31	4277	4.15	6014	4.99	8110	5.81	10611	6.59	13564	7.3	17017	7.93
	50			1627	2.95	2787	3.93	4214	4.95	5955	5.99	8054	7.03	10565	8.04	13538	9.01
	60					1342	3.4	2391	4.57	3704	5.81	5330	7.08	7322	8.37	9737	9.65
NTZ 271	30	3787	3.77	5503	4.59	7663	5.42	10324	6.25	13549	7.07	17400	7.89	21941	8.7	27232	9.49
	40	2678	3.69	4162	4.65	6012	5.62	8285	6.61	11044	7.6	14353	8.59	18279	9.59	22887	10.59
	50			2776	4.51	4264	5.65	6097	6.8	8338	7.98	11052	9.16	14307	10.37	18174	11.58
	60			-		2533	5.44	3872	6.78	5540	8.15	7600	9.55	10123	10.97	13187	12.41
NTZ430	30	5428	5.48	8058	6.86	11282	8.2	15246	9.46	20016	10.62	25684	11.6	32338	12.38	40068	12.9
	40	3402	5.02	5708	6.62	8554	8.3	12028	9.98	16220	11.62	21222	13.18	27128	14.6	34034	15.86
	50			3254	5.9	5574	7.86	8428	9.9	11910	11.98	16108	14.06	21130	16.08	27076	18.02
	60					2684	6.8	4782	9.14	7408	11.62	10660	14.16	14644	16.74	19474	19.3
NTZ 542	30	7574	7.54	11006	9.18	15326	10.8	20648	12.5	27098	14.14	34800	15.78	43882	17.4	54464	18.98
	40	5356	7.38	8324	9.3	12024	11.2	16570	13.2	22088	15.2	28706	17.18	36558	19.18	45774	21.18
	50			5552	9.02	8528	11.3	12194	13.6	16676	15.96	22104	18.32	28614	20.74	36348	23.16
	60					5066	10.9	7944	13.6	11080	16.3	15200	19.1	20246	21.94	26374	24.82

NTZ068 Low Temperature Refrigeration Condensing Unit Blue Color
