Parallel Compressor Refrigeration Condensing Unit 380V Cold Storage

Ask Lasest Price
Brand Name :	KUB
Model Number :	*KBVA-1306M ZB95KQE6*
Certification :	CE
Price :	12095-13587USD
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	1000 Piece/Pieces per Year
Delivery Time :	7

Add to Cart

Product Details
Company Profile

Parallel Compressor Refrigeration Condensing Unit 380V Cold Storage

Hot sale parallel compressor condensing unit for big cold storage

Below is a list of the configurations of one of our KUB units for this series

And our standard configuration instructions for this parallel unit: (The list and instructions are for informational purposes only, in practice we will have senior engineers tailor the appropriate configuration for you)

ZB95KQE x6 parallel unit
		quantity
Base frame (by figure)	340010001500	1
compressor	ZB95KQE	6
Oil heater		6
Shock-absorbing tube (domestic)	22	6
One-way valve	22	6
Oil storage oil separator	CC76,DN65	1
Exhaust shut-off valve	DN65	1
Seal the head	DN65
tee
Horizontal reservoir	CWX100, Import and Export 42,35	1
Import and export valves	DN40	1
Filter (domestic)	SR4811	1
Filter (domestic) D48		1
Respirator ()	3 points	1
1/4 charge valve		1
Liquid ball valve	35	1

Back to the balloon valve	DN80	1
Vapor separator type return tube 1		1

Return to the main tube	28	1
Electronic oil balance		6
Mirrors		1
Oil filter		1
Oil pressure differential controller		0
Hand valve		2
A pressure tube		1

The control section
Pressure Controller (KUB)		6
High-pressure meter (domestic)		1
Low-pressure meter (domestic)		1
Tableboard (by figure)		1
Hand valve 2 points		2
Pressure transmitter (4-20MA)		1
Pressure transmitter (4-20MA)		1

Parallel unit control box		1
Controller (New Asian PLC-Touchscreen)		1
Schneider contactor		1

Copeland compressor ZB series parallel unit parameters

Unit model	compressor			temperature-25℃		temperature-20℃		temperature-15℃		Interface(mm)				Form factor
Unit model	Model	Nominal	quantit	amount	power	amount	power	amount	power	inhale	suppl	exhaus	Infusio	l	w	H
6-12	ZB15KQWE	2HP	6	11220	10140	1440	10020	18000	9780	45	19	28	22	4500	1000	1500
6-18	ZB21KQWE	3HP	6	18000	13440	2220	13440	27300	13440	45	19	28	22	4500	1000	1500
6-24	ZB29KQWE	4Hp	6	24420	17760	3024	17820	36960	17820	45	22	35	22	4500	1000	1500
6-30	ZB38KQWE	5HP	6	30600	22500	3750	22560	46200	22560	45	22	35	22	4500	1000	1500
6-36	ZB45KQWE	6HP	6	36000	25800	4440	25860	54300	25860	57	22	35	22	4500	1000	1500
6-42	ZB48KQWE	7HP	6	39474	27906	4890	27954	59814	27948	76	28	42	28	4500	1000	1500
6-48	ZB58KQWE	8Hp	6	42300	35100	5550	34800	70200	34500	76	35	42	35	4500	1000	1500
6-54	ZB66KQWE	9Hp	6	53400	37200	6660	37500	81300	37800	76	35	42	35	4500	1o00	1500
6-60	ZB76KQWE	10HP	6	65400	43500	7980	43800	96600	44400	76	35	57	45	4500	1000	1500
6-72	ZB88KQWE	12HP	6	0	0	0	0	0	0	0	0	0	0	0	0	0
6-78	ZB95KQWE	13HP	6	69600	56100	9360	56400	117600	56580	89	42	76	57	4500	1000	1500
6-90	ZB114KQWE	15HP	6	81300	67080	1098	67320	138300	67560	89	42	76	57	4500	1000	1500
